Heliozoans - Scanning Electron Microscope images

Post by Ecki »

Heliozoans are the microbes that fascinated me most when I started with microscopy. Besides the well known larger heliozoans there are many very small species (10 µm diameter) that are nearly impossible to identify with a light microscope. Some of these small heliozoans reveal an amazing hidden beauty under the electron microscope.

These tiny heliozoans have axiopoda that get lost during preparation as well as siliceous scales. There are two typos of scales, tangential plate scales and radial scales. The tangential scales are usually much smaller.

Pterocystis pulchra, periplast with radial scales


Pterocystis pulchra, periplast with radial scales


Pterocystis pulchra, periplast with radial scales and tangential scales


Pterocystis pulchra, radial scales


Pterocystis pulchra, radial scales


Pterocystis striata, periplast with radial scales


Pterocystis striata, radial scales


Pseudoraphidiophrys formosa (=Pterocystis formosa), periplast with radial scales and tangential scales

Pseudoraphidiophrys formosa, radial scales and tangential scales


Pseudoraphidiophrys discoidea ( =Pterocystis discoidea), periplast with radial scales


Pseudoraphidiophrys discoidea, periplast with radial scales and tangential scales


Some of the radial scales remind me of flowers. It is quite astonishing how nature produces beauty even at the smallest scale.

These heliozoans used to belong to the genus Acanthocystis. Then they were moved to a distinct new genus Pterocystis (Ptero = wing, as theses scales show a wing-like profile in the light microscope). The species P. discoidea und P. formosa were subsequently moved further into the genus Pseudoraphidiophrys. Of course my identification is not 100% as we know very little about these heliozoans and there is very little published literature.

I wish you all a great 2014 with many interesting subjects under the microscope.

Best regards,
Ecki

Jacek
Posts: 5357
Joined: Sun Oct 02, 2011 7:00 am
Location: Poland

Post by Jacek »

great :shock:

Pau
Site Admin
Posts: 6030
Joined: Wed Jan 20, 2010 8:57 am
Location: Valencia, Spain

Post by Pau »

Really impressive!!
Are those scales visibles (even barely) with light microscopy?
Pau

Litonotus
Posts: 1394
Joined: Mon Jun 20, 2011 1:48 am
Location: Poland
Contact:

Post by Litonotus »

great, really impressive detail and atmosphere. Could you tell something about magnification used here?
my FB page

I'm looking for the the extemely rare V-IM magnification changer for the E800 scope. If you have seen a listing or have one for sale please let me know.

Ecki
Posts: 775
Joined: Wed Aug 13, 2008 2:04 am
Location: Cape Town, South Africa
Contact:

Post by Ecki »

Thank you all!
Are those scales visibles (even barely) with light microscopy?
Here is a link to Ferrys website: http://www.arcella.nl/pterocystis-spec

These are dried species in phase contrast. I don't think that these scales are visible normally.

The detail images are approximately 100.000x magnification, depends on your screen size :D

Litonotus
Posts: 1394
Joined: Mon Jun 20, 2011 1:48 am
Location: Poland
Contact:

Post by Litonotus »

thanks (:

light microsopy can do nothing here...
my FB page

I'm looking for the the extemely rare V-IM magnification changer for the E800 scope. If you have seen a listing or have one for sale please let me know.

arturoag75
Posts: 1600
Joined: Fri Feb 05, 2010 1:05 am
Location: italy
Contact:

Post by arturoag75 »

:shock: :shock: impressive and beautiful details hidden into Heliozoan wow..
Thanks for posting :wink:
Arturo

g4lab
Posts: 1437
Joined: Fri May 23, 2008 11:07 am

Post by g4lab »

Congratulations on having the new baby up and running!!!

flyer2o12
Posts: 223
Joined: Mon Jan 09, 2012 5:06 pm
Location: Ireland
Contact:

Post by flyer2o12 »

Hi Litonotus,

Which SEM are you using?

Marek Mis
Posts: 2586
Joined: Sat Jul 10, 2010 9:56 am
Location: Suwalki, Poland
Contact:

Post by Marek Mis »

Incredible images ! The structures look like leaves of some plant.

Marek

Ecki
Posts: 775
Joined: Wed Aug 13, 2008 2:04 am
Location: Cape Town, South Africa
Contact:

Post by Ecki »

Thank you, Marek.

Here I have two light microscopic images my friend Steffen made. He took the sample from a swamp and sent me half of it. We both prepared petri dishes from which I made my SEM preparations. When I find something interesting, he looks for the same species with a light microscope.

Here you have two images of Pterocystis with DIC:



On the last image Synura is present, too. The images were made for reference in pretty thick samples.

Best regards
Ecki

Litonotus
Posts: 1394
Joined: Mon Jun 20, 2011 1:48 am
Location: Poland
Contact:

Post by Litonotus »

I wonder how olympus 100/1,7 would perform... Or zeiss or olympus 150/1,35x objectives
my FB page

I'm looking for the the extemely rare V-IM magnification changer for the E800 scope. If you have seen a listing or have one for sale please let me know.

leonardturner
Posts: 711
Joined: Thu Mar 14, 2013 11:40 am
Location: Atlanta, GA, USA

Post by leonardturner »

Beautiful execution with a difficult instrument. Thank you!

pwnell
Posts: 2029
Joined: Fri Dec 18, 2009 4:59 pm
Location: Tsawwassen, Canada

Post by pwnell »

Please keep these coming. I love peeking deeper into the micro universe. If I had the money I'd get a SEM too and abscond from my day job.

Stefano B
Posts: 71
Joined: Wed Aug 07, 2013 1:56 pm

Post by Stefano B »

Hi Ecki,

which SEM are you using? Can you post some pictures of this microscope?
