Crustaceans

pwnell · Post by **pwnell** » Wed Oct 09, 2013 10:38 am

This is the third post of mine that actually all form part of a larger project I am working on with my daughter - Life In A Drop Of Water. Idea is just that - go out and see what life forms you can find in a single drop of water. The previous posts included the cyanobacteria (fluorescence pictures) and the ostracod / mite set. It is great to be privileged enough to be able to show your kid these things at home. She freaked out whenever I did something fancy such as the polarization of the amphipod - she loved seeing all those colours and learning about polarized light etc.

20130929-DSLR_IMG_0279.jpg by pwnell, on Flickr
Beaver Lake sample - amphipod,4x,POL

20130929-DSLR_IMG_0282.jpg by pwnell, on Flickr
Beaver Lake sample- amphipod,4x,POL+LAMBDA

amphipod by pwnell, on Flickr
Beaver Lake sample- amphipod,4x*1.25,POL+qwp+lp

copepod by pwnell, on Flickr
Beaver Lake sample- copepod,10x*1.25,dic, HF B stack of 41 images

20130929-DSLR_IMG_0386.jpg by pwnell, on Flickr
Beaver Lake sample- copepod,40x,dic

20130929-DSLR_IMG_0393.jpg by pwnell, on Flickr
Beaver Lake sample- copepod,40x,fluo-c4

arturoag75 · Post by **arturoag75** » Wed Oct 09, 2013 11:04 am

Waldo very nice shot...
In brigthfield ones i see some vignetting....why?
Arturo

pwnell · Post by **pwnell** » Wed Oct 09, 2013 11:09 am

Because the 4x/0.16 does not work with the universal condenser - I edited the black circular vignetting out but left a little.

arturoag75 · Post by **arturoag75** » Wed Oct 09, 2013 11:13 am

Thanks.....

pwnell · Post by **pwnell** » Wed Oct 09, 2013 11:21 am

I tried U-LC and U-ULC both neither works well, neither has a slot for QWP or LP so I returned both.

Jacek · Post by **Jacek** » Wed Oct 09, 2013 12:33 pm

brilliant

Marek Mis · Post by **Marek Mis** » Thu Oct 10, 2013 2:12 am

Very nice images !

Marek

Franz Neidl · Post by **Franz Neidl** » Thu Oct 10, 2013 5:31 am

hello pwnell,

congratulations for your pictures (specially Nr. 3 and 4).

Because the 4x/0.16 does not work with the universal condenser

In this case you could use a low power condenser (I made good experiences with it).

Franz

pwnell · Post by **pwnell** » Thu Oct 10, 2013 9:20 am

Franz Neidl wrote:congratulations for your pictures (specially Nr. 3 and 4).

Thanks!

Franz Neidl wrote:In this case you could use a low power condenser (I made good experiences with it).

As I mentioned above I tried Olympus' U-LC and U-ULC low power condensers designed specifically for the 4x and I could not see any difference between using those condensers vs. swinging out the TLD condenser in the universal condenser.

Besides - neither allows for any kind of lambda or quarter wave plates to be fitted, making above images impossible.

Franz Neidl · Post by **Franz Neidl** » Thu Oct 10, 2013 12:58 pm

hello pwnell,

NikonUser wrots about his experience with the Olympus Low Power conderser in this posting:
http://www.photomacrography.net/forum/v ... +condenser
His experience was a positive one. (His posting was the reason that I bougth a Nikon low power condenser. This is a good possibility to say THANK YOU to NikonUser for sharing his experience).

Franz

pwnell · Post by **pwnell** » Thu Oct 10, 2013 1:10 pm

Here are two photos with the 2x/0.08:

http://www.waldonell.com/images/2013082 ... G_0004.jpg

http://www.waldonell.com/images/2013082 ... G_0005.jpg

The first was taken with the TLO condenser swung out, the second with an expensive U-ULC condenser. I see virtually no difference, even at 100%.

jswatts · Post by **jswatts** » Wed Oct 23, 2013 11:59 pm

Man, that copepod stack is a-maz-ing!
