Deconvolution

Post by pwnell »

My first attempt at 3D deconvolution.

Original stack of 28 images using HF and Photoshop:

Deconvolution using cellSens Constrained Iterative:

René
Posts: 467
Joined: Sun Oct 08, 2006 4:22 am

Post by René »

Wow! Great result. Can you show us a single image of your stack, for a comparison??

CellSens, is that from Olympus? Is there freeware that you know of?

Best wishes, René

RogelioMoreno
Posts: 2981
Joined: Fri Nov 20, 2009 11:24 am
Location: Panama

Post by RogelioMoreno »

Waldo,

Amazing results!

Do you have any idea the price of cellSens Dimension?

Rogelio

Cyclops
Posts: 3084
Joined: Sat Aug 05, 2006 5:18 pm
Location: North East of England
Contact:

Post by Cyclops »

What on earth is deconvolution?
Canon 5D and 30D | Canon IXUS 265HS | Cosina 100mm f3.5 macro | EF 75-300 f4.5-5.6 USM III | EF 50 f1.8 II | Slik 88 tripod | Apex Practicioner monocular microscope

pwnell
Posts: 2031
Joined: Fri Dec 18, 2009 4:59 pm
Location: Tsawwassen, Canada

Post by pwnell »

René wrote:Wow! Great result. Can you show us a single image of your stack, for a comparison??
Here:
René wrote:CellSens, is that from Olympus? Is there freeware that you know of?
Yep, from Olympus. No, it is quite expensive. I have their 30-day trial and am trying to assess whether it is worth while.

pwnell
Posts: 2031
Joined: Fri Dec 18, 2009 4:59 pm
Location: Tsawwassen, Canada

Post by pwnell »

RogelioMoreno wrote:Amazing results!

Do you have any idea the price of cellSens Dimension?
Thanks. Not exactly sure, but I do know it is a couple of thousand dollars.

pwnell
Posts: 2031
Joined: Fri Dec 18, 2009 4:59 pm
Location: Tsawwassen, Canada

Post by pwnell »

Cyclops wrote:What on earth is deconvolution?
It is a process for reversing optical distortion. In theory, if you have all the parameters of a perfect lens and the other variables you can reverse optical distortions by calculating a function (PSF) that explains what happens to a point source of light as it travels from subject to the CCD.

Cyclops
Posts: 3084
Joined: Sat Aug 05, 2006 5:18 pm
Location: North East of England
Contact:

Post by Cyclops »

pwnell wrote:
Cyclops wrote:What on earth is deconvolution?
It is a process for reversing optical distortion. In theory, if you have all the parameters of a perfect lens and the other variables you can reverse optical distortions by calculating a function (PSF) that explains what happens to a point source of light as it travels from subject to the CCD.
I see, I think. Do you have an example in "normal" light?
Canon 5D and 30D | Canon IXUS 265HS | Cosina 100mm f3.5 macro | EF 75-300 f4.5-5.6 USM III | EF 50 f1.8 II | Slik 88 tripod | Apex Practicioner monocular microscope

pwnell
Posts: 2031
Joined: Fri Dec 18, 2009 4:59 pm
Location: Tsawwassen, Canada

Post by pwnell »

Well the first image is in fluorescence before deconvolution. So that would be "normal" light I guess? I have posted a reflected brightfield image in another thread on the fern stomata.

discomorphella
Posts: 607
Joined: Sun Oct 01, 2006 7:26 pm
Location: NW USA

Post by discomorphella »

Hi Waldo,

Brilliant. I've not used the Olympus product, but your results are certainly equivalent to the best that I've seen using AutoQuant and Huygens. Which objective did you use? And does cellSens allow for superresolution? And did Olympus say which algorithm they use?
Ironically, one of the main coders from AutoQuant is now employed in the CAD group at my company, and it was quite interesting to discuss PSF restoration with one of the principals when I was trying it out in lab. I have not had the opportunity to employ it on any homemade stacks, just no time, but your beautiful fern flourescence shot is certainly motivation to go and grab a stack.
There are some Matlab 3D MLE restoration implementations floating around the web. I have not tried them yet but if you had access to MATLAB its probably considerably less expensive than the Olympus or other dedicated software but will require a lot more programming on your part.

David

pwnell
Posts: 2031
Joined: Fri Dec 18, 2009 4:59 pm
Location: Tsawwassen, Canada

Post by pwnell »

Hey David,

Thanks - I am quite pleased myself. Still not 100% convinced it is necessarily "prettier" than the normal stacking but it most certainly seems more accurate from a biology perspective.

For this photo I used the LUCPLFLN 40x/0.6 for its ability to have a correction between 0 - 2mm. I am unsure whether cellSens does support superresolution. The algorithm is Advanced Maximum Likelihood Estimation in constrained iterative mode. This photo did not have spherical aberration corrections enabled.

soldevilla
Posts: 693
Joined: Thu Dec 16, 2010 2:49 pm
Location: Barcelona, more or less

Post by soldevilla »

In astronomy we use various softwares that include deconvolution. Some of them are for free, as CADET. Anyway, I have not ever gotten a correct result using deconvolution, I find it very difficult to quantify the defects of an image to reverse it. Instead Deconvolution,I use wavelets. And I use photoshop high pass filter, the "poor man" wavelet filter.

The picture you show also includes an enhancement for false color, very easy to do in photoshop too.

pwnell
Posts: 2031
Joined: Fri Dec 18, 2009 4:59 pm
Location: Tsawwassen, Canada

Post by pwnell »

soldevilla wrote:The picture you show also includes an enhancement for false color, very easy to do in photoshop too.
Which false colour?

soldevilla
Posts: 693
Joined: Thu Dec 16, 2010 2:49 pm
Location: Barcelona, more or less

Post by soldevilla »

Sorry, I do not get unread messages correctly.

The false color I get with a gradient layer and placing the colors to my liking. This is a powerful tool because it allows just highlight histogram levels we want to make it visible.
