Mayfly nymph

Post by Charles Krebs »

1, 2, 3, 5 and 6 are (partially) crossed polarizers in brightfield. 4 and 7 :smt119 are DIC.

With these I find the respiratory system and "tails" most interesting.

Olympus BHS, Olympus S Plan Apo 4/0.16. Brightfield with partially crossed polarizers. 22 image stack.

Olympus BHS, Olympus S Plan Apo 4/0.16. Brightfield with partially crossed polarizers. 12 image stack.

Olympus BHS, Olympus S Plan Apo 10/0.40. Brightfield with partially crossed polarizers. 20 image stack.


Olympus BHS, Olympus S Plan Apo 10/0.40. DIC illumination. 23 image stack.


Olympus BHS, Olympus S Plan Apo 10/0.40. Brightfield with partially crossed polarizers. 35 image stack.


Olympus BHS, Olympus S Plan Apo 10/0.40. Brightfield with partially crossed polarizers. 28 image stack.


Olympus BHS, Olympus S Plan Apo 10/0.40. DIC illumination (DIsney Chrome in this case :wink:). 28 image stack.
Last edited by Charles Krebs on Thu Nov 29, 2012 11:47 am, edited 1 time in total.

curt0909
Posts: 609
Joined: Wed Oct 26, 2011 10:06 am
Location: Pittsburgh, PA

Post by curt0909 »

All great. My favorites are the first and last.

pierre
Posts: 276
Joined: Mon Jan 04, 2010 12:37 pm
Location: France, Var, Toulon

Post by pierre »

A top work !

Impressive view of the internals.

Thanks for the share.
Regards

Pierre

Jacek
Posts: 5354
Joined: Sun Oct 02, 2011 7:00 am
Location: Poland

Post by Jacek »

Great series, you are unbeatable

Cactusdave
Posts: 1631
Joined: Tue Jun 09, 2009 12:40 pm
Location: Bromley, Kent, UK

Post by Cactusdave »

Great work, I love the first image. Are these stacked or is the depth due to judicious use of the aperture diaphragm? There is a quality of sharpness and solidity in these images and those from Jacek, that I much admire and envy. :)
Leitz Ortholux 1, Zeiss standard, Nikon Diaphot inverted, Canon photographic gear

Planapo
Posts: 1533
Joined: Tue Nov 07, 2006 2:33 am
Location: Germany, in the United States of Europe

Post by Planapo »

Lovely!
As I have a better understanding and a little practical experience 8) of how DIC is set-up and working now :wink: :D , I'd think that you've stacked the last one with the upper prism moved between single shots?

--Betty
Atticus Finch: "You never really understand a person until you consider things from his point of view
- until you climb into his skin and walk around in it."
Lee, N. H. 1960. To Kill a Mockingbird. J. B. Lippincott, New York.

Franz Neidl
Posts: 747
Joined: Wed Jan 14, 2009 11:59 am
Location: Italy

Post by Franz Neidl »

I like very much the first picture. It is looking like an extraterrestrial animal, maybe coming from Mars (not yet discovered from "Curiosity").

My questions: What objective did you use for the first picture: probably 4x,
but planapo, apo , fluor, achromatic ecc. ? It is a stack with how many pictures?

Franz

canonian
Posts: 890
Joined: Tue Aug 31, 2010 4:00 am
Location: Rotterdam, Netherlands
Contact:

Post by canonian »

Wonderful, Charles.
You keep raising the bar and you are a great inspiration to us all.
About the last one: a real winner for next months pm.net frontpage.

RogelioMoreno
Posts: 2962
Joined: Fri Nov 20, 2009 11:24 am
Location: Panama

Post by RogelioMoreno »

Beautiful set!

Rogelio

abpho
Posts: 1508
Joined: Wed Aug 17, 2011 7:11 pm
Location: Earth

Post by abpho »

Simply amazing.
I'm in Canada! Isn't that weird?

Ecki
Posts: 775
Joined: Wed Aug 13, 2008 2:04 am
Location: Cape Town, South Africa
Contact:

Post by Ecki »

Very nice.The depth of field of the first DIC image is amazing.

Wim van Egmond
Posts: 826
Joined: Tue Aug 15, 2006 9:28 am
Location: Berkel en Rodenrijs, the Netherlands
Contact:

Post by Wim van Egmond »

Beautiful! But that is not surprising. :)

Wim

Charles Krebs
Posts: 5865
Joined: Tue Aug 01, 2006 8:02 pm
Location: Issaquah, WA USA
Contact:

Post by Charles Krebs »

Thanks all for the kind remarks!

Dave and Franz....
I've gone back and added some info to each picture. The first two are with the Olympus 4/0.16 S Plan Apo; and all are from "stacks".

Betty...
I'd think that you've stacked the last one with the upper prism moved between single shots?
Good guess, and I wish that were the case :cry:. Unfortunately this is the result of a troubling aspects of my DIC set-up. With the 10X is it very difficult to get a homogenous background, both in terms of color and density. With a "grey" background I can tweak the DIC settings to get a useable result. But when the slider is dialed up into the "colors" it is hard to avoid a multi-color background. In this shot I just decided to "use it" since it made an interesting result with the geometry of the subject.

While the polarizers and DIC make for interesting results with the subject in the last three shots, I think I actually prefer the results from "plain old" brightfield and darkfield done a while ago (see what you think...):
http://www.photomacrography.net/forum/v ... php?t=8400
