profile view of amoeba test

Images made through a microscope. All subject types.

Moderators: rjlittlefield, ChrisR, Chris S., Pau

Charles Krebs
Posts: 5865
Joined: Tue Aug 01, 2006 8:02 pm
Location: Issaquah, WA USA
Contact:

profile view of amoeba test

Post by Charles Krebs »

I've posted my fair share of arcella over the years, but usually they are done looking directly into the top or bottom as here:
http://photomacrography.net/forum/viewtopic.php?t=6326

Had a rather unproductive slide last night, but there was one arcella with a very clear test that presented some nice side views.





Mitch, if you think these worms are a pain because they're always crashing through your shots... think about how this amoeba feels about them! :wink:


Mitch640
Posts: 2137
Joined: Sun Aug 15, 2010 1:43 pm

Post by Mitch640 »

Really beautiful images, as always. I do need to go look again at some brightfield images of yours though, to see what's possible.

OK, either Arcella is riding the worm, or he got eaten by it. LOL

john sp.
Posts: 42
Joined: Sat Oct 23, 2010 3:55 pm
Location: Tennessee, USA

Post by john sp. »

The "cross-section" that is revealed in those pictures is amazing. I don't think I've seen others that so fully reveal the amoeba inside, including the attachment points to the test.

Is it likely that this is a relatively young amoeba for its test to be so translucent?

John

Ecki
Posts: 775
Joined: Wed Aug 13, 2008 2:04 am
Location: Cape Town, South Africa
Contact:

Post by Ecki »

Looks like Arcella discoides to me. Normally they turn pretty fast when they are sideways under the coverslip. Nice catch!

Charles Krebs
Posts: 5865
Joined: Tue Aug 01, 2006 8:02 pm
Location: Issaquah, WA USA
Contact:

Post by Charles Krebs »

The new tests are the most clear, they darken as they age and absorb minerals (specifically iron and manganese).

Mitch.. unfortunately (for the amoba) it is not hitching a ride on the outside!

ABEL
Posts: 168
Joined: Wed Jul 07, 2010 5:30 am

Post by ABEL »

Wow ¡¡¡ Very nice Charles :shock:

In my aquarium there are many amoebas arcella :roll:

Franz Neidl
Posts: 747
Joined: Wed Jan 14, 2009 11:59 am
Location: Italy

Post by Franz Neidl »

Hello Charles!

an interesting picture!
How did you obtain this side view? Did you use petroleum jelly in order to obtain a bigger distance between slide and cover glass?

Franz

Charles Krebs
Posts: 5865
Joined: Tue Aug 01, 2006 8:02 pm
Location: Issaquah, WA USA
Contact:

Post by Charles Krebs »

Franz,

Not this time. I had a few "clumps" of debris on this slide that kept the coverslip elevated enough to provide plenty of maneuvering room for this amoeba.

If the intended subject is very small and it is obvious the 60X or 100X will be used, I try to avoid any such debris, so that as the water evaporates there is a time "window" where the subject is close to the coverslip, but not flattened or distorted. But sometimes I'll just take a dropper and gather a bit of whatever is floating on top of my jar and put it on the slide :wink:. I know that I'll miss many subjects because they will be too deep and resting on the slide itself. But sometimes this works OK because some subjects are at the edge of the debris up next to the coverslip. That's what happened here.

The petroleum jelly dabs in the corners method is used mostly for subjects that are fairly thick and would otherwise be crushed by the coverslip.
