"Sticky" hairs from a jumping spider's foot


Post new topic   Reply to topic    www.photomacrography.net Forum Index -> Administrator's Appreciation Gallery...Photography Through the Microscope
View previous topic :: View next topic
Author Message
rjlittlefield
Site Admin


Joined: 01 Aug 2006
Posts: 17874
Location: Richland, Washington State, USA

PostPosted: Sat Oct 28, 2006 10:51 pm    Post subject: "Sticky" hairs from a jumping spider's foot Reply with quote

Shot using aus Jena 100X NA 1.25 objective oiled to cover slip, subjects mounted in immersion oil, NA 1.2 condenser watered to slide, Olympus 80mm f/4 bellows macro used as 2.5X relay lens.
Heavily cropped and resized. Focus stepped from near to far.





A couple of weeks ago, I posted over in the macro forum some shots of the whole foot of a jumping spider. Jumping spiders have "sticky" feet that get their adhesion from Van der Wals forces acting on a multitude of tiny "setules" that are clustered at the ends of spatulate hairs. The setules can be clearly imaged using SEM, and the macro shots might just barely be resolving individual setules, so it was natural to ask what they'd look like with a high resolution compound microscope.

Shown above are a couple of answers to that question.

I'm pretty sure that the top set of pictures is one spatula lying flat, while the lower set is a different spatula lying a bit on its side. It seems that each spatula has a few widely spaced bristle-shaped projections on one side, and a dense regular array of setules on the other side. Spacing of the setules measures 0.7 to 0.8 microns, smack in the middle of the size range that we guessed from some of the SEM pictures that people tracked down.

This was my first foray into high magnification photomicroscopy. I'm pretty satisfied with how these shots came out, but the equipment setup was definitely what you'd call "cobbled together" and the whole affair was rather more tedious than I'd like to do on a regular basis. (This, mind you, from a man who regularly shoots 70-100 frame stacks for extended depth of field. Hhmm... Think )

--Rik

PS. These shots are green channel only. Color added no useful info and I found the CA fringes distracting.

Here's what a larger section of the slide looked like, using a 10X objective with no cropping. Shot through the oil drop left over from the 100X objective. The bubbles are in the immersion oil used as mountant.
Back to top
View user's profile Send private message Visit poster's website
Ken Ramos



Joined: 27 Jul 2006
Posts: 6947
Location: lat=35.4005&lon=-81.9841

PostPosted: Sun Oct 29, 2006 4:27 am    Post subject: Reply with quote

Rik said:

Quote:
and the whole affair was rather more tedious than I'd like to do on a regular basis. (This, mind you, from a man who regularly shoots 70-100 frame stacks for extended depth of field. Hhmm... )


You are really taking this Jumping Spider apart aren't you Rik Question Laughing Talk about tedious...just stitching all these images together to make the composites is enough to try my patience. Confused An interesting post you have here though and the images are great, however, I wonder about that last one though, from all the spidery parts scattered around. Though I am not especially keen on spiders, I cannot help but to feel a bit sorry for it. Laughing
_________________
However, while there is grace where in all that I might live, while there is still breath in my being, while I may or may not accomplish anything more in life than to be living, I shall reflect upon the past, applying it to the present, for to possibly perceive to a near certainty, the outcome of the future.

Ken 2014
Back to top
View user's profile Send private message
rjlittlefield
Site Admin


Joined: 01 Aug 2006
Posts: 17874
Location: Richland, Washington State, USA

PostPosted: Sun Oct 29, 2006 12:15 pm    Post subject: Reply with quote

Quote:
...all the spidery parts scattered around...

Ken, I never thought I'd hear you express sympathy for a spider! Very Happy

But that strew does look a bit messy, doesn't it?

It was pretty interesting putting it together, though.

What I did, working at 45X under a dissecting scope, was to scrape off some of the hairs into a small pile on the slide. That by itself was not simple, considering the small size of the hairs and the fact that they're designed to stick to anything they touch.

Then I dropped a tiny bit of immersion oil -- about a microliter -- onto the pile. I was expecting problems with wetting -- figured I'd get a zillion little bubbles trapped in the hairs. But that didn't happen at all. The oil wicked right in and wetted everything perfectly. In a couple of seconds, what I had was a small pile of hairs still stuck to the slide, but completely wetted with immersion oil.

That situation didn't last long, however.

As I watched, intensely wishing I had a video camera running, each of the hairs individually detached itself from the slide and quickly floated to top dead center of the oil drop. They reminded me ever so much of what happens with those foam pads that kids play with in a swimming pool. You know -- the ones you just can't resist sinking by standing on them, but then they get loose and come shooting to the surface like that sub in Hunt for Red October? Fun to watch!

Pretty straightforward after that, as far as slide prep was concerned. Plop on a cover slip, a drop of water on the condenser, oil for the lens, and it was ready to go.

The tedious part was largely in getting the photo gear set up. I only have a binoc head, so I had to work through that. First I tried using my point-and-shoot through the eyepiece. That worked, sort of, but the camera doesn't have manual focus, and it doesn't have a remote release, just a 10-second self-timer. Overall, it was annoying, unpredictable, and I wasn't getting quite the quality I wanted, so I switched strategies and worked up the scheme of using a macro lens almost like a projection eyepiece, focused on the aerial image at its usual position 1 cm down the tube to keep the objective happy.

After I had the optics worked out, it took some more messing around to find hairs that were properly positioned to tell the story, and to shoot a collection of focus depths that I thought would work.

Photoshopping the montages was really quite relaxing after wrestling with the other stuff!

But hey, at least now I've got the images captured so the info won't disappear immediately, and I'm sure I learned some reusable technique along the way.

By the way, you asked in another post about the purpose/value of scale bars.

Short answer is that I can't think of a better way to record how big these hairs are. The visible detail matches what you'd see in the center of the eyepiece at 1000X (100X objective, 10X eyepiece), but on my monitor, they have to be displayed at about 2000X or detail gets lost because the monitor's pixels are so big. I could write "Shown here at 1900X and 2500X", but then what does that mean when the same web page gets shown on a large-screen monitor?

Seems like no matter what we do, it's hard to get a good immediate impression of size for things that are so small we have no direct experience with them.

--Rik
Back to top
View user's profile Send private message Visit poster's website
beetleman



Joined: 04 Aug 2006
Posts: 3578
Location: Southern New Hampshire USA

PostPosted: Sun Oct 29, 2006 4:08 pm    Post subject: Reply with quote

It seems like you got some spectacular shots of those hairs Rik. Some sacrifices always have to be made in the name of science and knowledge and you went the extra mile here
_________________
Take Nothing but Pictures--Leave Nothing but Footprints.
Doug Breda
Back to top
View user's profile Send private message Send e-mail
Ken Ramos



Joined: 27 Jul 2006
Posts: 6947
Location: lat=35.4005&lon=-81.9841

PostPosted: Sun Oct 29, 2006 4:42 pm    Post subject: Reply with quote

Rik said:
Quote:
By the way, you asked in another post about the purpose/value of scale bars.

Short answer is that I can't think of a better way to record how big these hairs are. The visible detail matches what you'd see in the center of the eyepiece at 1000X (100X objective, 10X eyepiece), but on my monitor, they have to be displayed at about 2000X or detail gets lost because the monitor's pixels are so big. I could write "Shown here at 1900X and 2500X", but then what does that mean when the same web page gets shown on a large-screen monitor?

Seems like no matter what we do, it's hard to get a good immediate impression of size for things that are so small we have no direct experience with them.


Good enough answer for me. Wink What was that sound? Scale bars being tossed out the window, of course. Laughing No, I am sure they serve some purpose but I just don't feel like purposing with them. Laughing

A great explaination of how you went about all this Rik, very interesting indeed and thanks Very Happy . Now put that poor spider back together and lets see something else. The poor thing will probably be on a telethon here soon... Idea can spiders draw disability?
_________________
However, while there is grace where in all that I might live, while there is still breath in my being, while I may or may not accomplish anything more in life than to be living, I shall reflect upon the past, applying it to the present, for to possibly perceive to a near certainty, the outcome of the future.

Ken 2014
Back to top
View user's profile Send private message
rjlittlefield
Site Admin


Joined: 01 Aug 2006
Posts: 17874
Location: Richland, Washington State, USA

PostPosted: Sun Oct 29, 2006 7:27 pm    Post subject: Reply with quote

Ken Ramos wrote:
No, I am sure they serve some purpose but I just don't feel like purposing with them.

Ken,

I've been scratching my head all afternoon about this issue of scale bars, and I think I've got it figured out. Sorry to be taking this so seriously, but...

The whole question (I think...) boils down to whether the photographer wants the viewer to know the size of the subject accurately and reliably.

If there's a scale bar accurately placed in the image, then not much can go wrong.

If there is not a scale bar placed in the image, then there are gobs of things that can go wrong. For example...
  • The image may be cropped, so it doesn't correspond to full field in the eyepiece.
  • The viewer may guess wrong about what "full field" means in your setup.
  • The image may get separated from info about what lenses were used. (This happens all the time in publication.)
Without the scale bar, and following Jahn's guidance*, the viewer might guess that the microscope has 1600 microns across the field with a 10X objective, 160 microns with a 100X. Then he might figure that the pictures are pretty much full field, which means that with the 100X objective they'll be about 160 microns diagonal, or about 133 microns width.

Presumably this sort of calculation works pretty well for direct viewing,or Jahns wouldn't have described it so carefully.

But does it work for photos?

Not very well, it seems. Let's consider some examples. The pictures that I posted above were heavily cropped, only about 51 and 27 microns in width. That's a error of up to 5X from the estimate of 133 microns. In one of Walt's posts, I had calculated that his field width was probably around 400 microns (at 400X), but his stage micrometer showed only 125. Error of 3X from my estimate. Even when the pictures really are full field, things can still go wrong to a lesser degree. As you and I discussed in a topic back in March, the number I very carefully estimated for your Meiji's field width was still off by a ratio of 4:5. (I estimated 4 mm at 40X, you measured 5 mm.)

In these cases...

Without the scale bar, the viewer could laboriously estimate/calculate a size that's between 20% and 500% incorrect, assuming that nothing goes wrong in his number-crunching.

Or with the scale bar, the viewer could just measure the correct size, within 10% or so, using little more than counting off thumb widths.

Does that make the rationale more clear?

Quote:
Now put that poor spider back together...

'Tis written: "All the king's horses and all the king's men..." I'm not even that good! Very Happy

--Rik

* T.L.Jahn, "How to Know the Protozoa", 1st edition, 1949, pages 13-14.
Back to top
View user's profile Send private message Visit poster's website
Ken Ramos



Joined: 27 Jul 2006
Posts: 6947
Location: lat=35.4005&lon=-81.9841

PostPosted: Sun Oct 29, 2006 7:57 pm    Post subject: Reply with quote

It all makes sense there Rik but it also seems like a lot of trouble, especially to match the scale to that of a cropped image or an image that has just been enlarged from the original size. I am not one to play around with numbers much, mainly because they give me a headache and I never was good with them anyway and I have my school transcripts to prove it. Laughing Thanks Rik. Very Happy
_________________
However, while there is grace where in all that I might live, while there is still breath in my being, while I may or may not accomplish anything more in life than to be living, I shall reflect upon the past, applying it to the present, for to possibly perceive to a near certainty, the outcome of the future.

Ken 2014
Back to top
View user's profile Send private message
rjlittlefield
Site Admin


Joined: 01 Aug 2006
Posts: 17874
Location: Richland, Washington State, USA

PostPosted: Mon Oct 30, 2006 9:09 am    Post subject: Reply with quote

Ken,

It's true, the way that I've always done scale bars involves some number-crunching. That's OK for me, 'cuz my head is wired for crunching numbers (and reading cereal boxes). But I'll be the first to admit that it gets a bit tiresome, and there's certainly some chance for error on my part.

However, there's a much easier approach that involves no number-crunching at all. The magic device is "stage micrometer", and it's nothing more than a tiny ruler printed on a microscope slide. Tiny means like 10 microns per division -- 100 tick marks in 1 mm. Walt gave us a nice picture of one as the third image in this post.

Given a stage micrometer, putting in a scale bar is all images, no numbers. Here's one approach. Take a picture of the micrometer using the same optics as your subject. In your favorite photo editing tool, insert the picture of the micrometer as a partially transparent layer over your subject. Draw the scale bar, using the micrometer as a guide. Then remove the layer that shows the micrometer. If you do this before you crop & resize, then the scale bar just goes along for the ride.

Hhmm... Sounds a lot simpler than what I've been doing, even for high-mag macro work. Maybe I should get me one of those stage micrometer thingies. Christmas is coming, tra la, tra la! Very Happy

--Rik

Afternote: Ah! I see that Graham explained this earlier today, in his post over in the Technique forum. Well, at least I'm reassured that our explanations pretty much match! Very Happy
Back to top
View user's profile Send private message Visit poster's website
Charles Krebs



Joined: 01 Aug 2006
Posts: 5671
Location: Issaquah, WA USA

PostPosted: Sun Nov 05, 2006 9:13 pm    Post subject: Reply with quote

Nice Rik.... we need to get you playing around with that microscope a little more often! Wink
