 Posted: Sun Jul 22, 2007 5:22 pm Post subject: Pectinate grooming spur of a paper wasp (Polistes dominulus) |
 |
|
Somehow you folks got me started on grooming spurs. This is from one of the Polistes dominulus wasps featured in an earlier posting. The structure of the wasps' grooming apparatus is conceptually similarly to that of the Pogonomyrmex flying ants that I posted earlier, but the details are very much different.
--Rik
Technical: Canon 300D camera, 10X NA 0.25 microscope objective on 150mm extension, 95 frames stacked at 0.00025" spacing. Dual fiber illuminator with Kleenex tissue diffuser. Helicon Focus with manual retouching of stacking halo and physical debris on the specimen. |
|
| Back to top |
|
 |
Ken Ramos
Joined: 27 Jul 2006
Posts: 6372
Location: Western North Carolina
|
| Posted: Sun Jul 22, 2007 6:47 pm Post subject: |
|
|
Well if I had any hair to groom, I would be thankful for a comb but of course it would be better than lying in the driveway and licking yurself too!   Hey great shot there Rik!
_________________
Ken Ramos
Rutherford Co., Western North Carolina
"Social isolate?" |
|
| Back to top |
|
|
beetleman
Joined: 04 Aug 2006
Posts: 3578
Location: Southern New Hampshire USA
|
| Posted: Mon Jul 23, 2007 4:01 pm Post subject: |
|
|
An excellent closeup Rik. Incredible detail & sharpness. Awesome results for all your effort.
_________________
Take Nothing but Pictures--Leave Nothing but Footprints.
Doug Breda |
|
| Back to top |
|
|
Walter Piorkowski
Joined: 14 Aug 2006
Posts: 407
Location: South Beloit, Ill
|
| Posted: Mon Jul 23, 2007 7:16 pm Post subject: |
|
|
As Doug said, excellent detail and focus. I really like how you were able to get enough light through the subjects translucent body to bring out details on the opposite side. I assume some quality backlighting was involved?
Walt |
|
| Back to top |
|
|
rjlittlefield
Site Admin
Joined: 01 Aug 2006
Posts: 7323
Location: Richland, Washington State, USA
|
| Posted: Mon Jul 23, 2007 9:54 pm Post subject: |
|
|
Thanks for the compliments, guys.
| Walter Piorkowski wrote: | | I assume some quality backlighting was involved? |
Um, gee, it's hard to say. The setup for this beast is illustrated here, over in the Technique forum. There's a gray card behind the subject, a Kleenex tissue tent around the subject and lens, and I just played with the fiber heads until the thing looked right. From the position of the lights that I remember, there would have been little or no direct illumination from in back of the focus plane. On the other hand, there would have been a fair amount from only slightly in front of the focus plane, which could act a lot like "darkfield" and brighten up the subject compared to the background.
In direct examination under a dissecting scope, what struck me was the crystal transparency of the lower part of the grooming spur, and I played with the illumination until that aspect came through in the photo.
Don't know what else I can say, Walt. I always hate to admit that it's a mystery why one of my pics came out good, but, um, it's a mystery?
--Rik |
|
